Specifically designed for Ophthalmic Surgery, the Lab-Med Opmaster 506P is also suitable for endoscopic sinus surgery and is currently being used for some plastics & gynae procedures. The Opmaster 506P provides a theatre quality table that meets the extensive demands of the busiest Day Surgery Units. Offering an extremely stable platform, excellent access for the surgeon, with an exceptional height range; powered table movements ensure ease of use for theatre/nursing staff. The head section levelling / articulation feature gives greater scope to patient positioning and stability. The manually operated foot section is removable. Pressure relief memory foam mattresses provide excellent comfort for patients up to 225kgs (34st).
|
OPMASTER 506P |
TECHNICAL SPECIFICATIONS |
|
|
Overall |
Length |
1990 mm |
|
|
Overall Width |
710 mm |
|
|
Mattress Width |
600 mm |
|
|
Height Range |
578 - 978 mm (top of mattress) |
|
|
Capacity |
225 kg (34st) (patient prone) |
|
|
Weight |
160 kg |
|
Powered Movements |
Head Section |
-36° to +36° |
|
|
Back Section |
0° to +60° |
|
|
Trendelenberg |
0° to -20° |
|
|
Reverse Trendelenberg |
0° to -15° |
|
Manual Movements |
Foot Section |
0° to -87° (detachable) |
|
|
Head Section has an additional levelling/articulation feature giving greater scope for patient postion, stability and comfort. |
|
|
Power Supply |
Battery |
24v DC 4.5AH capacity |
|
|
Control Voltage |
24vDC |
|
|
Mains |
230v 50/60Hz single phase |
|
|
(For charging batteries either in-situ or via charging station) |
|
|
|
Inlet Fuses |
T x 2A 250v x 2 (UK & EU) |
|
|
Battery Discharge |
Typically 12 duty cycles |
|
|
Battery Recharge |
Typically 6 to 8 hrs |
|
Standard Features |
Drop down removable cot side rails |
|
|
|
Euro size side bars to trunk and back sections |
|
|
|
Sculptured "Rubens Type" head mattress |
|
|
|
Pressure-relief memory foam mattresses |
|
|
|
IV pole sockets |
|
|
|
Perinea Cut-out |
|
|
|
Detachable foot section |
|
|
|
Four castor braking and selectable directional locking |
|
|
|
Push/pull grab handles at head end |
|
|
Optional Features |
Standard head section (permanent) |
|
|
|
Padded cot side covers |
|
|
|
Oxygen cylinder stowage (PD size) |
|
|
|
150mm diameter castors |
|
