The Lab-Med Ltd Opmaster 508 has been designed to provide a theatre quality table that meets the extensive demands of the busiest Day Surgery Units. The Opmaster 508 offers excellent access for the surgeon, ease of use for nursing staff, a 225kg patient capacity, exceptional height range, lateral tilt (non-lateral tilt option available) and to the complete this high quality specification pressure relief mattresses are standard providing excellent patient comfort. The Opmaster 508 offers versatility, mobility and reliability.
|
OPMASTER 508 |
TECHNICAL SPECIFICATIONS |
|
|
Overall |
Table Length |
2030 mm |
|
|
Table Width (over mattresses) |
600 mm |
|
|
Table Width (over cot sides) |
710 mm |
|
|
Table Height (with Lateral Tilt) |
700 - 1135 mm (top of mattress) |
|
|
Table Height (without Lateral Tilt) |
660 - 1095 mm (top of mattress) |
|
|
Capacity |
225 kg (34st) (patient prone) |
|
|
Weight |
180 kg |
|
Table Adjustments |
Head Section |
-30° to +30° (detachable) |
|
|
Back Section |
0° to +60° |
|
|
Trendelenberg |
0° to -25° |
|
|
Reverse Trendelenberg |
0° to -15° |
|
|
Foot Section |
0° to -100° detachable) |
|
|
Lateral Tilt (Optional) |
-15° to +15° left and right |
|
Standard Features |
Drop down and detachable cot side rails |
|
|
|
Euro accessory rails to trunk and back sections |
|
|
|
Push/pull grab handle at head end |
|
|
|
Lightweight, adjustable & removable foot section |
|
|
|
IV Pole socket and stowage |
|
|
|
Braking controls at head end |
|
|
|
Four castor braking and selectable directional locking |
|
|
|
Oxygen cylinder stowage (PD size) |
|
|
|
X-ray cassette tunnel & translucent table top |
|
|
|
Perinea cut-out |
|
|
Optional Features |
Padded cot side covers |
|
|
|
Push/pull grab handle at foot end |
|
|
|
Oxygen cylinder stowage (D size) |
|
|
|
150mm diameter castors |
|
|
|
Stowage basket/box |
|
|
|
Braking controls at foot end |
|
